Main Struts

Deep Blue Yacht Supply is your trusted source for all Buck Algonquin Main Struts. Contact us today to procure your Buck Algonquin Main Struts. All Main Struts come bored (Shaft bearings and baseholes can be installed upon request.) to accept a shaft bearing with setscrews installed - Sold each

View as

Sort by

Display per page

Product(s)	Bore Size	Shaft Angle	Forward Drop	Aft Drop	Base Width	Base Length	Barrel Length	Offset	Price
MS1 125 Main Struts	1-1/4 inch	12º	5-1/16 inch	6-3/32 inch	3-3/8 inch	5-3/4 inch	5 inch	1-5/16 inch
MS2 200 Main Struts	2 inch	12º	7-3/4 inch	8-3/4 inch	4-5/8 inch	6-1/4 inch	5 inch	1-23/32 inch	N/A
MS3B2375 Main Struts	2-3/8 inch	7-1/2º	11-3/4 inch	12-1/2 inch	8 inch	8-1/4 inch	5-5/8 inch	2-1/8 inch	N/A
MS4 200 Main Struts	2 inch	21º	5-1/4 inch	7-1/16 inch	4-7/8 inch	6 inch	4-7/8 inch	0	N/A
MS5 200 Main Struts	2 inch	11º	8-31/32 inch	9-15/16 inch	7 inch	7 inch	5 inch	7 inch	N/A
MS6 2375 Main Struts	2-3/8 inch	10-1/2º	10-3/4 inch	11-25/32 inch	7-3/4 inch	8-1/4 inch	5-5/8 inch	4-3/32 inch	N/A
MS7 175 Main Struts	1-3/4 inch	17º	6-3/8 inch	7-13/16 inch	6 inch	9 inch	4-7/8 inch	4-3/16 inch	N/A
MS8 150 Main Struts	1-1/2 inch	12º	6-15/16 inch	7-15/16 inch	4 inch	6 inch	4-3/4 inch	5/8 inch	N/A
MS9 200 Main Struts	2 inch	14º	8-15/16 inch	10-5/16 inch	6-1/4 inch	6-3/4 inch	5-5/8 inch	2-7/16 inch	N/A
MS10 150 Main Struts	1-1/2 inch	19º	5-5/8 inch	6-29/32 inch	3-1/4 inch	5-1/2 inch	4 inch	3-3/32 inch	N/A
MS10X200BH Main Struts	2 inch	14º	6-7/16 inch	7-5/8 inch	5 inch	6 inch	5 inch	1-9/16 inch	N/A
MS10XL200B Main Struts	2 inch	15º	7-7/16 inch	8-11/16 inch	5 inch	6 inch	5 inch	1-11/16 inch	N/A
MS10XLW200 Main Struts	2 inch	14º	8-13/32 inch	9-19/32 inch	5 inch	6 inch	5 inch	1-3/4 inch	N/A
MS12 1625 Main Struts	1-5/8 inch	13º	6-13/16 inch	7-13/16 inch	4-3/8 inch	7-1/2 inch	4-1/2 inch	2-11/16 inch	N/A
MS14 150 Main Struts	1-1/2 inch	11-1/2º	6-21/32 inch	7-1/16 inch	3-5/16 inch	5-7/8 inch	4 inch	2-1/4 inch	N/A
MS15 200 Main Struts	2 inch	13º	9-9/16 inch	10-3/4 inch	5-3/4 inch	7 inch	5-1/4 inch	-1/16 inch	N/A
MS15 2375 Main Struts	2-3/8 inch	13º	9-7/32 inch	10-25/32 inch	5-3/4 inch	7 inch	7 inch	-1-3/4 inch	N/A
MS16 200 Main Struts	2 inch	23º	7-7/8 inch	9-25/32 inch	6-1/4 inch	9-1/4 inch	4-7/8 inch	2-7/8 inch	N/A
MS19 150 Main Struts	1-1/2 inch	15º	9-9/16 inch	10-7/8 inch	5-3/4 inch	8 inch	5 inch	6-11/16 inch	N/A
MS20 150 Main Struts	1-1/2 inch	16-1/2º	7-1/2 inch	8-21/32 inch	4-7/8 inch	8 inch	5 inch	2-3/8 inch	N/A
MS21 175 Main Struts	1-3/4 inch	14-1/2º	8-23/32 inch	10-1/16 inch	5 inch	6-5/8 inch	5 inch	1-13/16 inch	N/A
